IPL Filters for Aesthetic
LaserOptec offers full types of IPL Filters, Double-Cut Filters, Light Pipes and windows used in aesthetic application.
With more than 20 years deep experienced in medical IPL beauty and cosmetic industry, we could offer you an overall optical solutions to meet your needs.
Specialized for aesthetic treatment application
Durable hard dielectric coating
Deep UV blocking & efficiency heat control
Clear Aperture 100%
Full type IPL Filters, Double-Cut Filters, Light Pipes, Light Guides
Steep transition slope
High transmission pass band to >95%
Custom shapes and sizes
Unsurpassed performance and reliability
In-house OEM and custom manufacturing solutions
| Coating | Durable hard dielectric coating |
|---|---|
| Wavelength | 300-1200nm |
| Transmission | T≥95% |
| Cut-off | Blocking T≤1% |
| Substrate | H-K9L, N-BK7, UVFS, Sapphire, etc. |
| Filter Types | Single plate, Stepped plate, Bonding plate, Cube, Hexahedron, Trapezoid, Pyramid |
| Center Wavelength | ±5nm, ±10nm |
| Clear Aperture | Coating surface 100% |
| Common wavelengths and applications | Acne removal at 430nm, freckle removal at 530nm, skin rejuvenation at 560nm and hair removal at 640nm |
| Filter Features | Cut off ultraviolet and infrared light deeply and effectively transmit specific wavelengths, such as whitening, skin tenderness, and hair removal. |
Product Testing Standards:
Visual test: MIL-PRF-13830, Environmental test: MIL-STD-810
Durability test: MIL-C-48497, Anti-reflection coating test: MIL-C-675C
Applications:
E-light, IPL, OPT, Q-switched laser, photon skin rejuvenation, hair removal and other medical cosmetology instruments.
- Single Plate Filter
- Hair Removal Filter
- Di-electric Coating Filter
- Color Glass Filter
- Hexahedron Light guide
- Trapezoid Light Pipes
- Pyramid Light Pipes
- Light Pipes for Diode Laser
- Light Pipes
- Light Guides
- Double-Cut Filter
- IPL Filter
- Sapphire Filter
- Longpass Filter
- Shortpass Filter
- Stepped Plate Filter
- Bonding Plate Filter
Di-electric Coating Filter
Hexahedron Light guide
Light Pipes
Single Plate Filter
IPL Filter
Stepped Plate Filter
Cosmetic Filter Spectrum
Cosmetic Filter Spectrum
| Typical Specifications | Custom size and Custom coatings, wavelengths are available |
|---|---|
| Single Plate Filter | 51x15x0.5、56x15x0.5、 68x15x0.5、 68x12x1、 68x13x1、 68x14x1、68x15x1、60x50x1、 65x60x2 |
| Hexahedron Light guide | 40x8x6、40x8x8、 40x10x8、 40x10x10、 34x24x7.8、 40x15x8、 40x18x8、40x26x8、40x30x8、40x34x8、40x38x8、45x40x8、40x40x8、40x20x10、40x40x10、45x15x10、 48x40x10、 50x38x10、 50x40x10、 50x50x10、60x25x15、60x50x15、64x34x8、 72x57x16 |
| Trapezoid Light Pipes | 65x57x50x15、65x57x35x15、65x57x30x12、65x60x50x15、65x60x30x12、50x57x30x12 |
| Light Guides for Diode Laser | 10x10x2、15x13x2、 17x15x3、 17x17x3、 15x30x2、 13x13x60、14-40x87.5x14、12x23x59.5、 10x15x80、 10x10-12x15-80 |
We offer full types of IPL Filters, Double-Cut Filters, Light Pipes and windows used in aesthetic application, please contact us for more information.
